Airport Baggage X Ray Machine 600 * 400 Mm Tunnel Size With 12 Months Warranty

  • 1
  • 2

Brand Name : SECUPLUS

Model Number : spx6040

Certification : CE FCC ROHS

Place of Origin : CHINA

MOQ : 1 unit

Price : Negotiable

Payment Terms : L/C, T/T, Western Union

Supply Ability : 300 units per month

Delivery Time : 5-8 working days

Packaging Details : Plywood Pallet

Tunnel size(mm) : 600(L)*400(W)

Penetration : 38 mm steel

Warranty : 12 months

In stocks : About 20 units

Packing : Plywood Pallet

Service : 24 hours online

other size : 5030/6550/8065/10080/100100/150180

X-ray Generator : 140KV/160KV

Contact Now

Airport X ray Security Scanner with CE FCC ROHS in huge stocks with high performance

SPECIFICATIONS
Physical
Specification
Unit weight (kgs)
512
Unit size (mm)
2194.7(L)*902(W)*1362.5(H)
Gross weight (kgs)
700
General Specification
Penetration
Typical 38mm, guarantee 34mm
X ray leakage
Typical 1.0 μGy/h, guarantee 1.5 μGy/h
Wire Resolution
Typical AWG40, guarantee AWG38
X-ray Generator (single)
Anode Voltage
160 KV
Anode power
0.5mA
Generate angle
80 degree upward

General Specifications
Tunnel size(mm)
600(L)*400(W)
Conveyor Speed(m/s)
0.22
Conveyor height(mm)
690
Conveyor Max Load(kgs)
170
X ray dose per each inspection
1.5 μGy
X ray leakage
<0.25 μGy / h
Penetration
38mm steel
Wire Resolution
dia 0.0787mm copper wire (AWG40)
Penetration Resolution
dia 0.202mm copper wire (AWG32) under three-step aluminum wedge 9.5mm, 15.9mm, 22.2mm
Spatial resolution:
Horizontal:dia1.0mm,Vertical: dia1.0mm
Power Consumption
max. 1KW

Main Features:

Multilingual operation
Automatic built in test and self diagnosis
Secure access Key
Uninterruptable power supply (UPS)
Threat alert and material classification
Auto archiving
Network-Ready
Energy saving design
One key turn off
Drugs and explosives inspection
Indication of the date and time
Baggage counter

Details Images:

Airport Baggage X Ray Machine 600 * 400 Mm Tunnel Size With 12 Months Warranty

Airport Baggage X Ray Machine 600 * 400 Mm Tunnel Size With 12 Months Warranty

Related products

  1. Arched Metal Detector: Single/6/8/12/16/18/24/33/45 zones optional
  2. Under Vehicle Inspection Equipment: Fixed, Mobile, Hand-Held
  3. Explosive and Trace Detector: Fixed, Hand-Held
  4. Dangerous Liquid Scanner: Fixed, Hand-held
  5. X-ray Vehicle Scanner
  6. Hand Held Metal Detector

Company Workshop

Airport Baggage X Ray Machine 600 * 400 Mm Tunnel Size With 12 Months Warranty

Airport Baggage X Ray Machine 600 * 400 Mm Tunnel Size With 12 Months Warranty

Airport Baggage X Ray Machine 600 * 400 Mm Tunnel Size With 12 Months Warranty

After-Sales Service

* Training how to instal the machine, training how to use the machine.

* Engineers available to service machinery overseas.

Pre-Sales Service

* Inquiry and consulting support.

* Sample testing support.

* View our Factory.

FAQ

Q1: Are you a factory or trading company?
A: We are the biggest professional manufacturer of security equipment with almost 10 years experiences in Shenzhen china.

Q2: What is your MOQ?
A: Normally MOQ 1pcs and the price is negotiable for large quantity.

Q3: What is your leadtime?
A: 3-7 working days after received the payment.

Q4: How does your factory do regarding quality control?
A: We control every production process in accordance with ISO9001, ISO14001, ISO18001 and CE certification, Radiation safety certification, FCC, ROHS, CE.

Q5: What is your after-sale service?
A: 100% guarantee on our product; install instruction and video support; software debugging with remote control support; The whole unit 1 year free guarantee.
